M57 planetary imaging

Posted: Jun 7th, 2020

Technical Info

Telescope/Lens: Sky-Watcher 130pds

Camera: QHY5III178M Cool

Mount: HEQ5 Pro

Guide Scope: Svbony 60/240mm

Guide Camera: Qhy5L-II-c

Software: APT, PHD2, APP, AutoStakkert!, Lightroom, Registax, FitsWork, GIMP

Accessories: Baader MPCC Mk3, Svbony MFW, Svbony LRGB filters

Exposure:

7000 x 1" ISO/Gain: 51 - L

50 x 60" ISO/Gain: 0 - R

40 x 60" ISO/Gain: 0 - G

48 x 60" ISO/Gain: 0 - B

30 x 120" ISO/Gain: 15 - Ha

Yellow zoneLight Pollution:

Starye Keny, Russia

M57 PLANETARY IMAGING

Telescope/Lens: Sky-Watcher 130pds
Camera: QHY5III178M Cool
Mount: HEQ5 Pro
Guide Scope: Svbony 60/240mm
Guide Camera: Qhy5L-II-c
Software: APT, PHD2, APP, AutoStakkert!, Lightroom, Registax, FitsWork, GIMP
Accessories: Baader MPCC Mk3, Svbony MFW, Svbony LRGB filters

Starye Keny, Russia
Light Pollution: Yellow zone

Exposure:
7000 x 1" ISO/Gain: 51 - L
50 x 60" ISO/Gain: 0 - R
40 x 60" ISO/Gain: 0 - G
48 x 60" ISO/Gain: 0 - B
30 x 120" ISO/Gain: 15 - Ha

I did a bit of experimenting with lucky imaging. Layer 1: 90% of the best frames out of 7,811 (about 7,000) at 1 second each at maximum gain. Processed in AutoStakkert!, resampled 2x, deconvolution in Registax. Layer 2: color data from the previous image in "Merge" mode in GIMP with transparency around 30–40%. Layer 3: same as Layer 2, but in "HSL Color" mode. The atmosphere wasn’t very cooperative, and guiding was terrible for most of the night—still not sure what the issue is, maybe something with the guide mount or the mount itself.

Original size: https://deepskyhosting.com/vj2YDY6
Author: alesterre

5 h 15 m

2086

I did a bit of experimenting with lucky imaging.

Layer 1: 90% of the best frames out of 7,811 (about 7,000) at 1 second each at maximum gain. Processed in AutoStakkert!, resampled 2x, deconvolution in Registax.
Layer 2: color data from the previous image in "Merge" mode in GIMP with transparency around 30–40%.
Layer 3: same as Layer 2, but in "HSL Color" mode.

The atmosphere wasn’t very cooperative, and guiding was terrible for most of the night—still not sure what the issue is, maybe something with the guide mount or the mount itself.

Resolution: 1907x1445 px

Scale: 1145 KB
